Monday Afternoon — Manipulating Files in Unix

Welcome back, newly formed bioinformaticians!

Let’s get stuck into some more Unix commands.

Make sure you are back in the directory bioinfo_adventures.

If we want to copy a file, we use the cp command. Let’s copy the file grandeur.txt to create a new file called Darwin.txt

cp grandeur.txt Darwin.txt

What do you see with ls now?

TASK: What happens if you try to use cp on a directory? Can you get it to work?

If we want to remove a file, we use the command rm

rm Darwin.txt

What do you see with ls now?

TASK: What happens if you try to use rm on a directory?

• Remember the similar command rmdir, which works to remove directories—but only if they are empty.

TASK: Is there a way to use rm on a directory? How is that different from rmdir?

Take care with rm!: In Unix, the rm (remove) command is one of the most powerful—and dangerous—tools. When you use rm, it permanently deletes files and directories without sending them to a recycle bin or trash. Once a file is removed, it is usually impossible to recover without advanced tools. Be especially careful when using wildcards like *, which can remove multiple files at once. Adding the -r (recursive) option will delete entire directories, including their contents, making rm -rf particularly unforgiving. Always double-check your commands, or use rm -i to prompt before each removal.

If we want to rename or move a file, we use the mv command. If we just issue the command and a file name, it renames the file. Try this and then see what you see with ls

mv grandeur.txt origin.txt

TASK: What happens if you try to use mv on a directory? Why is mv ok, but cp/rm not?

But if we specify a file path for the destination file pointing outside the current directory, the file is moved rather than just renamed.

Try this

mv origin.txt bioinfo_fun

What do these command show us?

ls
cd bioinfo_fun
ls

What has now changed?

The cat command will show you the contents of a text file.

cat origin.txt

• (https://en.wikipedia.org/wiki/Cat_(Unix))

Shortcuts and messages from the terminal

There are two quick shortcuts you can use to navigate around the Unix prompt.

• If a file already exists in the place you are specifying, you can autocomplete the command. By pressing the tab button. Type cat o and then press the tab button.
• Also, you can use the up ↑ and down ↓ arrows to take you up and down the set of previous commands, which can then be edited by using the left ← and right → arrows to move along the line.

TASK: What happens if you type a non-existent command? Type this:

evolve

You will get something like

evolve: command not found

It’s important that we read the messages that the terminal shows us. In this case it means that our system has no program (available to us) called evolve. If we want to use it, we have to install it first. This is a made up example, and we don’t need to install anything.

TASK: What happens if you issue a command when there is no file for it to act on?

cat Darwin.txt

Downloading and searching a text file

curl is a command-line tool used to transfer data to or from a server using various protocols, including HTTPS, FTP, and many more. It supports a wide range of operations, from downloading files and web pages to interacting with applications. Its versatility makes it a staple tool for developers and system administrators for tasks like web content retrieval, API testing, and file transfers.

It’s a very powerful yet complex tool, but we will use it in a very simple way.

curl -o voyage_of_the_beagle.txt https://www.gutenberg.org/cache/epub/944/pg944.txt

Here’s a breakdown of the command:

• -o voyage_of_the_beagle.txt: This tells curl to output the downloaded content to a file named voyage_of_the_beagle.txt.
• The URL is the address of the resource you want to download.
• After executing the command, the content will be saved in the file voyage_of_the_beagle.txt in the current directory.

We now have a text file of Darwin’s Voyage of the Beagle.

Remember the command cat will direct the entire contents of a file to the screen. Sometimes files are large, or even impossibly large, and we save our sanity if we just print the first (or last) lines of a file. The head and tail commands are used for this purpose. Compare outputs of these commands

cat voyage_of_the_beagle.txt

head voyage_of_the_beagle.txt

tail voyage_of_the_beagle.txt

By default both head and tail print the first or last 10 lines of a file. You can change this behaviour by adding the -n NUMBER parameter, for example:

head -n 100 origin.txt

The grep command is another powerful command.

• https://en.wikipedia.org/wiki/Grep

Let’s use it in a very simple way to find all the lines in which Darwin uses the term handsome

grep handsome voyage_of_the_beagle.txt

More grep

Here are a few useful variations of the grep command using different flags to demonstrate its flexibility. We’ll use “handsome” as the target word in Voyage of the Beagle.

Case-Insensitive Search The -i flag makes the search case-insensitive, so it will match “Handsome,” “handsome,” or any other capitalization.

grep -i "handsome" voyage_of_the_beagle.txt

Print Line Numbers The -n flag adds line numbers to the output, which can be handy for reference.

grep -n "handsome" voyage_of_the_beagle.txt

Invert Match (Lines that Don’t Contain the Word) The -v flag inverts the match, showing all lines that don’t contain the search term.

grep -v "handsome" voyage_of_the_beagle.txt

Count Matches The -c flag counts the number of lines that contain matches, instead of displaying them.

grep -c "handsome" voyage_of_the_beagle.txt

Show Context (Before and After Matches) The -B and -A flags show the number of lines before and after each match, respectively. Here’s how to show 3 lines before and after each match:

grep -B 3 -A 3 "handsome" voyage_of_the_beagle.txt

• what was Darwin forced to admit about the ladies of Buenos Aires?

Show Only Matching Words The -o flag will print only the matched part of the line.

grep -o "handsome" voyage_of_the_beagle.txt

Show Whole Words The -w flag ensures that grep only matches whole words. Without it, grep would also match substrings (e.g., “handsome” would match part of “handsomest”).

grep -w "handsome" voyage_of_the_beagle.txt

These variations of grep make it a powerful tool for finding exactly what you’re looking for in any text!

File permissions in Unix

Unix-based systems, including macOS, manage file and directory access through permissions. These permissions determine who can read, write, or execute files and directories. permissions are divided into three categories for each file: user, group, and others. For more details, check the Wikipedia page on Unix file permissions.

The Read (R), Write (W), and Execute (X) permissions are often referred to as the “rwx” permissions. These permissions determine what actions can be performed on a file or directory by different users or groups.

• Read (R): When a user has read permission on a file, they can view the file’s contents and copy it. For directories, read permission allows a user to list the directory’s contents. Without read permission, a user can’t access or see the content of a file or directory.
• Write (W): Write permission allows a user to modify the contents of a file or create new files within a directory. For directories, it also permits the deletion or renaming of files within that directory. Without write permission, a user can’t make changes to the file or directory.
• Execute (X): Execute permission primarily applies to executable files or scripts. When a user has execute permission on a file, they can run it as a program. For directories, execute permission allows a user to enter and access the directory’s contents. Without execute permission on a directory, even if a user has read access, they can’t navigate into that directory.

These permissions are crucial for maintaining security and control over file and directory access in Unix-based systems, allowing administrators to restrict or grant specific rights to different users or groups, enhancing the overall integrity and usability of the system.

To view permissions, use the ls -l command, which stands for long format, displaying Unix file types, permissions, number of hard links, owner, group, size, last-modified date-time and name.

ls -l

You will get a list of files with information about them.

Here is how it looks for one particular file on my computer. The format will be the same but details different for files on your your computer.

ls -l -rw-r--r--@ 1 mksmab staff 1207982 4 Oct 11:22 voyage_of_the_beagle.txt

The output from ‘ls -l -rw-r–r–@ 1 mksmab staff 1207982 4 Oct 11:22 voyage_of_the_beagle.txt’ represents file information in a long format.

Here’s how to interpret it:

• -rw-r--r--: This part represents the file’s permissions. In this example, “voyage_of_the_beagle.txt” has read and write permissions for the owner, but only read permissions for the group and others.
• 1: This number indicates the number of hard links to the file. In this case, there’s only one link to the file.
• mksmab: This is the owner of the file, which is “mksmab.”
• staff: This is the group associated with the file, which is “staff.”
• 1207982: The file’s size in bytes. In this example, “voyage_of_the_beagle.txt” is 1,207,982 bytes in size.
• 4 Oct 11:22: These fields represent the date and time when the file was last modified. In this case, the file was last modified on October 4th at 11:22 AM.
• voyage_of_the_beagle.txt: Finally, this is the filename.

This output provides comprehensive information about the file’s permissions, ownership, size, modification timestamp, and more, making it a useful reference when working with files and directories in a Unix-based system.

Changing File permissions

*chmod: Changing permissions To modify permissions, use the chmod command. permissions are assigned using a numerical code or symbolic notation.

Numerical Mode:

• 4: Read permission
• 2: Write permission
• 1: Execute permission

Each permission is represented by a digit, with the sum of these digits representing the permission level. For example, to give read and write permissions to the user and group, you would use chmod 664 filename.

Symbolic Mode:

• u: User
• g: Group
• o: Others
• a: All (user, group, and others)

Give read and write permissions to user and group

Numerical Mode:

chmod 664 filename

Symbolic Mode:

chmod u=rw,g=rw filename

In this example, the 664 in numerical mode or u=rw,g=rw in symbolic mode grant read and write permissions to the user and group, while others have no permissions (o=).

Give yourself permission to execute a file

Numerical Mode:

chmod 700 filename

Symbolic Mode:

chmod u=rwx filename

In this example, the 700 in numerical mode or u=rwx in symbolic mode grants read, write, and execute permissions to the user, while the group and others have no permissions (g=,o=).

Give everyone permission to do anything to a file

Numerical Mode:

chmod 777 filename

Symbolic Mode:

chmod a=rwx filename

In this example, 777 in numerical mode grants read, write, and execute permissions to the user, group, and others. This setting allows anyone to do anything to the file.

Remember that it’s essential to use file permissions responsibly, especially when granting extensive permissions like 777, as it can pose security risks. Always consider the implications and only apply such permissive settings when necessary.

Redirection

Currently, the output of every command to placed in the command line (which is wiped clean after every session). Hoe can we output a command to a text file to save it? Bash contains a multitude of commands for redirecting inputs and outputs between different commands. It is a very powerful utility which allows you create pipelines and keep track of progress. We’ll just cover the > operator here, but there is a lot more to discover online.

grep handsome voyage_of_the_beagle.txt > handsome.txt

cat handsome.txt

The > operator redirects the output of a command await from STDOUT (the command line) and writes to a file. If the file doesn’t already exist then it tries to create it.

TASK: What is the difference between > and >>?

Other operators allow you to take the output of one command as use it as input to another. Other commands allow you to redirect error/warning messages to one file and successful outputs to another.

Bash is a programming language

A full introduction to bash is beyond this course, but it is important to know that Bash is a full programming language with variables, logic and loops.

Create and call a variable

my_first_number=1

echo $my_first_number

TASK: Why did I use the command echo before calling the variable? What happens if you just call the variable on its own?

TASK: What happens if you put spaces between the equals sign and the number?

Make a for loop

for var in 1 2 3 4 5
do
	touch $var.txt
done

Wildcards

Bash was created predominantly to run commands on files held by an OS. Therefore, for the most part it assumes any text passed to it is either a command or a file path. This allows bash to do some useful shortcuts!

We’ve created five files. What is the easiest way to delete these files? With the ? wildcard, which means “any single character”.

ls

rm ?.txt

ls

Creating a Shell Script

A shell script is a text file that contains a series of commands and instructions written in a scripting language, typically designed for command-line interaction. These scripts are executed by a shell interpreter, which is often the default command-line interface of an operating system, such as Bash on most Unix-like systems or zsh on macOS.

Shell scripts are used to automate tasks, execute a sequence of commands, or perform system administration tasks in a more efficient and repeatable manner. They can include conditional statements, loops, variables, and other programming constructs, allowing users to create complex sequences of actions. Shell scripts are widely used for tasks like file manipulation, data processing, system maintenance, and more. They are a fundamental tool for power users, system administrators, and developers working in command-line environments.

So, let’s create a shell script in zsh. If you are going to be using the command line to handle files in a given directory, it might be useful to ensure all your files have Unix-compatible names by replacing spaces with underscores in filenames. Choose a target directory on your Mac, say the Desktop and cd to it. You can edit the text for a shell script in any text editor (although take care with Word). The macOS TextEdit would work, but if you want to stay on the command line, you can just cat the text into the file.

cat > replace_spaces.sh <<EOF
#!/bin/zsh
for file in *; do
  if [ -f "$file" ]; then  # Check if it's a regular file
    newfile="${file// /_}"
    mv "$file" "$newfile"
  fi
done
EOF

Use ls -l to look at the file and its permissions.

Making the Script Executable

To make the script executable, use the chmod command:

chmod +x replace_spaces.sh

Running the Script

Execute the script in your current directory:

./replace_spaces.sh

This script replaces spaces with underscores in all filenames within the current directory.

Hang on! Why do we need that ./ in front of the script name?

In Unix-like operating systems, including macOS, when you want to run a script or an executable file located in the current directory, you typically need to prefix the command with ./. Here’s why:

• Current Directory: By default, the system doesn’t include the current directory (the directory you are in) in the list of directories searched for executable files. This is a security measure to prevent accidentally running malicious or unintended scripts or programs.

• Path Lookup: When you execute a command without specifying a path (e.g., script.sh), the shell looks for the command in directories listed in the system’s PATH environment variable. These directories are predefined, like /usr/bin or /usr/local/bin. The current directory is not part of this search path.

• Explicit Execution: To run a script or an executable in the current directory, you need to explicitly specify the path to the file. The ./ notation tells the shell to look for the file in the current directory. For example, ./script.sh indicates that you want to run the script.sh file in the current directory.

By requiring ./, Unix-like systems make it clear that you are running a command from the current directory intentionally, reducing the risk of accidentally executing a potentially harmful script with the same name as a system command. It’s a safety measure to ensure that you explicitly indicate the location of the script you want to run.

Editing permissions Using Finder

You can also change file permissions using the macOS Finder:

• Right-click the file or folder.
• Select “Get Info.”
• Expand the “Sharing & permissions” section.
• Click the lock icon and enter your password to make changes.
• Use the dropdown menus to adjust permissions for users and groups.

Understanding Root and sudo

Root is the superuser in Unix-based systems with unrestricted access. sudo (superuser do) allows authorized users to execute commands as the superuser or another user. sudo is often needed to install programs on Unix-like systems because many system-level tasks, including software installation and configuration, require administrative privileges. Be cautious when using sudo as it can modify system files. Learn more on the Wikipedia page about sudo.

For example, on the macOS you logged in as a user don’t have permission to add a file to one of the directories used by the operating system.

Try this

touch /etc/test_file.txt

To run a command as a superuser using sudo:

sudo touch /etc/test_file.txt

Always exercise caution and avoid using sudo unless necessary. With sudo, you have the power to modify or delete critical system files, change user permissions, and alter the system in ways that can lead to serious, sometimes irreparable, damage. An accidental sudo rm or other poorly written command can cause system-wide issues.

macOS Security Considerations

macOS includes security features like Gatekeeper and SIP (System Integrity Protection) that restrict the execution of programs and scripts to ensure system integrity. You may encounter permission issues when running scripts or software downloaded from the internet. To overcome this, you can adjust security settings in the System Preferences to allow execution of specific applications and scripts. Always be vigilant about the security implications when modifying these settings to protect your system. It’s because macOS is so fussy about such things that we will be moving on to to Notebook servers tomorrow and not trying to install any bioinformatics software on your MacBooks. Also,some bioinformatics software may not yet be optimized for the Apple Silicon (ARM64) processors. To run these applications, Apple provides Rosetta 2, which translates x86_64 instructions for ARM processors. Yet more faff!

Time for coffee!

Text files and the command line

This afternoon we will learn how to manipulate and analyse text files on the Unix command line.

Downloading some toy files

Let’s download an archive with some toy files to use in the next sections. This time we use a command called wget, which stands for ‘web get’

wget "https://github.com/telatin/learn_bash/archive/refs/tags/2022.tar.gz"

tar: extracting the archive

We have downloaded an archive in the .tar.gz format. tar is another compressed format very popular in UNIX systems. To decompress it, we use the tar command

tar -xzf 2022.tar.gz

Where we combine some swiches:

• -x switch to extract the archive,
• the -z switch to decompress it,
• the -f parameter to specify the filename (immediately after).

Try typing ls: can you see that a new directory was created?

Use ls -l to check the content of the new directory

total 16
-rw-r--r--   1 telatin  bioinfo  6660 26 Oct 12:30 README.md
drwxr-xr-x   6 telatin  bioinfo   192 26 Oct 12:30 _readme_maker
drwxr-xr-x   5 telatin  bioinfo   160 26 Oct 12:30 archives
drwxr-xr-x  18 telatin  bioinfo   576 26 Oct 12:30 files
drwxr-xr-x   7 telatin  bioinfo   224 26 Oct 12:30 misc
drwxr-xr-x  21 telatin  bioinfo   672 26 Oct 12:30 phage
drwxr-xr-x  13 telatin  bioinfo   416 26 Oct 12:30 scripts

The first column lists the permissions of the file and its type: if the first char is d it’s a directory, if it’s - it’s a file, if it’s l it’s a link (“shortcut” as called in Windows).

Two columns specify the owner and the group of the file. We just created them expanding an archive, so these files are owned by us.

We have a column specifying the size of the file, and the last column is the name of the file.

To make our tutorials easier, we will now rename the directory to learn_bash:

mv learn_bash-2022 learn_bash

find

The find command is used to search for files in a directory. Unlike ls, it can search for files matching a pattern, and it can search in subdirectories.

In the Linux flavour of find, if you omit a path to scan, it will assume its the current directory. In the version of find installed with macOS, you need to specify the path to scan, like find ..

Some examples:

• List all the files and subdirectories or a directory:

# Remember that [tab] just means to press Tab, to autocomplete

find learn_b[tab]

Lots listed! Might be worth using that clear command.

• List only the subdirectories:

# If you type `-type f` you will print only the files instead
find learn_bash -type d

• List only items ending by ‚’.faa‚’:

find learn_bash -name "*.faa"

wild characters and shell expansion

We introduced with the last command a special character, the asterisk *, that meant ‚’any string‚’. In find, we must surround patterns with double quotes.

We will now try to exemplify the power of shell expansion.

• * matches any string, including the empty string.
  • For example, find learn_bash -name "*.faa" will match all files ending by .faa, while find learn_bash -name "*gene*" will list all files containing the string gene.
• ? matches any single character.
  • For example, find learn_bash -name "*R?.fastq.gz" will match all files with the string R followed by exactly one more character, then a dot and ending with any string. Examples are ‚’sample1_R1.fastq.gz’, ‚’sample2_R1.fastq.gz’ etc but this woulr not work for sample2_R11.fastq.gz
• [A-Z], [a-z] or [0-9] matches any character in the range.
  • For example, find learn_bash -name "sample[0-9].*" will match all files with the string sample followed by a digit, then a dot and ending with any string. Examples are again ‘sample1_R1.fastq.gz’, ‚’sample2_R1.fastq.gz’ etc but not ‚’sample1_R11.fastq.gz’, ‚’sample2_R1345.fastq.gz’ etc’.
• {this,that} matches any of the strings separated by commas.
  • For example, ls learn_bash/phage/reads/*_R{1,2}.fastq.gz"’ will match all files ending by ‚’_R1.fastq.gz‚’ and ‚’_R2.fastq.gz‚’. However find learn_bash -name "*_R{1,2}.fastq.gz" will not work here (because the curly braces are interpreted by bash before find).

When we use this syntax, the command will receive the expanded list of matching files. Try with ‘ls’ to see what happens:

ls -lh learn_bash/files/*.png

Text files

The wc command is used to count the number of lines, words and characters in a file. This only applies to simple text files.

wc learn_bash/README.md

If we want, we can print only the lines (with -l), words (with -w) or characters (with -c).

How many lines are there in learn_bash/files/README.md?

You have now met the commands wc, head and tail: they are all non-interactive commands. To interactively browse a file, we can use the less command.

less learn_bash/files/origin.txt

Basic Navigation Keys when using less:

• Up Arrow or k: Scroll up one line at a time.
• Down Arrow or j: Scroll down one line at a time.
• Spacebar or f: Scroll forward one page (full screen).
• b: Scroll backward one page.
• G: Go to the end of the file.
• 1G or gg: Go to the beginning of the file.
• /search_term: Search for a specific term within the file. Replace search_term with your search query.
• n: Move to the next occurrence of the search term.
• N: Move to the previous occurrence of the search term.

Try /grandeur

To exit less and return to the shell prompt, press the q key. This action closes the less pager and brings you back to your command line.

A useful option for less is -S, which will not wrap long lines, meaning that long lines will not be split.

cut

The cut command is used to extract columns from a file. The general syntax is cut -d DELIMITER -f FIELDS FILE(s). By default the delimiter is a tab, so you don’t need to specify

# Check the first two lines of the file first
head -n 2 learn_bash/files/cars.csv

# Print only the columns model and cyl (1 and 3)
cut -d "," -f 1,3 learn_bash/files/cars.csv

• How could we extract the same columns, but from the file learn_bash/files/wine.tsv (tab-separated)?

sed

The sed command is used to search and replace text in a file. The general syntax is sed -e 's/OLD/NEW/g' FILE(s)

# We can replace the "," with a "|"
sed 's/,/|/g' learn_bash/files/cars.csv

Here we used an obscure syntax, which will become familiar with practice, as it’s borrowed by other tools and even programming languages: s/SOMETHING/OTHER/g. The s means ‚’substitute‚’, the g means ‚’global‚’ (i.e. replace all the occurrences.

Try to replace only the first occurrence, removing the g:

sed 's/,/---/' learn_bash/files/cars.csv

sort

The sort command is used to sort the lines of a file. By default, it sorts alphabetically.

sort learn_bash/files/cars.csv

Some options:

• -t, to specify the delimiter (in this case, a comma)
• -k FIELDS to sort by the given fields (fields being a number or a set of numbers separated by commas)
• -n to sort numerically (this is a switch)
• -r to sort in reverse order (this is a switch)

sort -n -t, -k 2 learn_bash/files/cars.csv

Typing multi-line commands

Sometimes our terminal can become too crammed with text, and we would like to type a command in multiple lines. This is possible with the \ character, which tells the shell that the command continues on the next line. This can be useful to make commands clearer to read:

wget -O origin.txt \
 "https://raw.githubusercontent.com/telatin/learn_bash/master/files/origin.txt"

Note that when you type a backslash at the end of a line and then press enter, the shell will print a different prompt (usually a >), which means that the command is not finished yet. This greater-than is not to be confused with the redirection operator.

End of Day 1

And that’s enough for one day! Okay, so you are now bioinformaticians. It may not feel like it, but you have started your journey into microbial bioinformatics!

Your brain has been rewired and you need a rest.

Additional resources

Follow the links in the column to the left to additional resources and to the glossary that you might want to explore to reinforce your learning.
